Mounting accessories NauticProfil® system

Numerous mounting options allow for the flexible use of our NP S2, NP R1, and NP R2 profiles in all installation situations. For attaching the mounting plate, we recommend using metric screws of size M2.5 or sheet metal screws with a diameter of 2.2–2.9 mm and a maximum screw head height of 2.2 mm.

Mounting clips

Brackets are available with and without angles and in various materials. The mounting clips with friction pins are protected against longitudinal displacement of the profile and are therefore also suitable for vertical installations.

Spring clip 0°

24 x 18 x 5.8 mm;
corrosion-resistant spring steel

Article number:
FL/SCLIP-0/0/001

Mounting clip
adjustable 75°

35.5 x 19 x 22 mm;
corrosion-resistant spring steel

Item number:
FL/CLIP-Adjustable

Mounting clip 0°
with friction pin

33 x 19 x 7 mm;
plastic

Item number:
FL/CLIP-1/0/001

Mounting clip 15°
with friction pin

35 x 21 x 11 mm;
plastic

Item number:
FL/CLIP-1/15/001

Mounting clip 30°
with friction pin

35 x 22 x 15 mm;
plastic

Item number:
FL/CLIP-1/30/001

45° mounting clip
with friction pin

35 x 19 x 18 mm;
plastic

Item number:
FL/CLIP-1/45/001

Mounting clip 60°
with friction pin

35 x 18 x 20 mm;
plastic

Item number:
FL/CLIP-1/60/001

Magnetic mounting clips

Versatile use, simplest installation – the mounting clips are combined with strong permanent magnets to permanently attach the NP S2, NP R1 and NP R2 profiles to all magnetic surfaces, such as steel beams and cladding.

Magnetic mounting clip 0° with friction pin

33 x 20 x 13 mm;
Magnet & Plastic

Item number:
FL/MCLIP-1/0/001

Magnetic mounting clip 15° with friction pin

35 x 21 x 17 mm
Magnet & Plastic

Item number:
FL/MCLIP-1/15/001

Magnetic mounting clip 30° with friction pin

35 x 21 x 21 mm;
Magnet & Plastic

Item number:
FL/MCLIP-1/30/001

Magnetic mounting clip 45° with friction pin

35 x 20 x 24 mm;
Magnet & Plastic

Item number:
FL/MCLIP-1/45/001

Magnetic mounting clip 60° with friction pin

35 x 20 x 26 mm;
Magnet & Plastic

Item number:
FL/MCLIP-1/60/001

Other mounting accessories

NauticProfil® safety clip for NP S1 (CS)

Fall protection Cs

31.1 x 35 x 23.5 mm;
stainless steel

Article number:
NP/S1-MP/SC/CS

NauticProfil® safety clip for NP S1 (CR)

Fall protection cr

33.5 x 35 x 23.5 mm;
stainless steel

Article number:
NP/S1-MP/SC/CR

NauticProfil® safety clip for NP S1 (LAF-2)

Fall protection-Laf

37 x 35 x 23.5 mm;
stainless steel

Article number:
NP/S1-MP/SC/LAF-2

Mounting plate for NP W mounting profile

Flnp_W-Plate_Ala

90 x 31 x 5 mm;
anodized aluminum

Article number:
NP/W-PLATE/ALA

Bracket for NP R1 mounting profile (recommended)

R-bracket

2x 74.93 x 19.69 x 34.43 mm
galvanized steel

Article number:
NP/R-BRACKET

Retaining spring for NP R1 mounting profile

Flnp-R_Spring

Galvanized steel

Article number:
NP/R-SPRING

Accessories NauticProfil® System

NP flat cable

UV-resistant, 4 x 2.5 / 3.45 mm²

Article number:
FLNP/FCABLE-UV

NP Protection Gel

to protect the NP piercing contacts

Article number:
NP/P-GEL/75ML

NP protective plate

Article number:
NP/P-PLATE

NP heat shrink tubing

30 mm heat shrink tubing, self-adhesive and weldable, for protecting the open end of the flat cable

Item number:
NP/SHRINK-TUBE

NP disassembly tool

Article number:
NP/DTOOL/1

Wago 2-conductor terminal block, box

0.08 mm² – 2.5 mm², CAGE CLAMP® connection

Article number:
FL/CONNECTOR/2

Wago 3-conductor terminal block, box

0.08 mm² – 2.5 mm², CAGE CLAMP® connection

Article number:
FL/CONNECTOR/3

Wago 5-conductor terminal block, box

0.08 mm² – 2.5 mm², CAGE CLAMP® connection

Article number:
FL/CONNECTOR/5

MCS Midi clutch

Article number:
NP/F-CONNECTOR

MCS Midi connector

Article number:
NP/M-CONNECTOR

Plug connector coupling

Including seal for cables with a diameter of 5 to 7 mm

Item number:
NP/IP68-FCONNECTOR

Plug connector

Including seal for NP flat cables 4 x 3.5 for cables with 2.5 to 4 mm²

Item number:
NP/IP68-MCONNECTOR
